🚀 DevOps Deployment: Dockerize and Deploy a 3-Tier App with Helm on Kubernetes

As modern applications evolve, DevOps workflows bridge the gap between development and operations. In this post, we’ll walk through how to Dockerize a 3-tier web application—consisting of a frontend, backend, and PostgreSQL database—and deploy it to a Kubernetes cluster using a custom Helm chart.

You’ll learn:

• How to structure a 3-tier app for containerization
• Dockerfile tips for Go-based services
• Kubernetes deployment best practices
• How to create a reusable Helm chart for real-world deployments
• How to manage trusted CA certificates across Linux, Docker, and JVM-based systems

🧱 3-Tier Architecture Overview

We’ll build and deploy the following:

• Frontend – a static site (React, Vue, or Hugo)
• Backend – a Go HTTP API
• Database – PostgreSQL

graph TD
client[Browser]
client --> nginx[Frontend Nginx]
nginx --> goapi[Backend Go App]
goapi --> pg[PostgreSQL DB]

📦 Step 1: Dockerize Each Tier

🔹 Frontend Dockerfile (e.g., Hugo + Nginx)

1
2
3
4
5
6
7
8
9

# Stage 1 – Build Hugo site
FROM klakegg/hugo:0.120.0-ext AS builder
WORKDIR /app
COPY . .
RUN hugo

# Stage 2 – Serve with Nginx
FROM nginx:alpine
COPY --from=builder /app/public /usr/share/nginx/html

🔹 Backend Dockerfile (Go API)

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

# Stage 1 – Build
FROM golang:1.21 AS builder
WORKDIR /app
COPY . .
RUN go build -o server .

# Stage 2 – Run
FROM alpine
COPY --from=builder /app/server /server
EXPOSE 8080
ENTRYPOINT ["/server"]

🔹 PostgreSQL (Official Image)

No Dockerfile needed, just reference postgres:15-alpine in your docker-compose.yml or Kubernetes deployment.

🧪 Step 2: Local Testing with Docker Compose

Use Compose to test locally before pushing to Kubernetes:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

version: '3.9'
services:
  frontend:
    build: ./frontend
    ports: [ "80:80" ]
    depends_on: [ backend ]

  backend:
    build: ./backend
    ports: [ "8080:8080" ]
    environment:
      DB_HOST: postgres
    depends_on: [ postgres ]

  postgres:
    image: postgres:15-alpine
    environment:
      POSTGRES_DB: app
      POSTGRES_USER: user
      POSTGRES_PASSWORD: pass
    volumes:
      - dbdata:/var/lib/postgresql/data

volumes:
  dbdata:

✅ Once confirmed working, you’re ready for the cluster.

☸️ Step 3: Prepare Kubernetes Manifests

Break deployments into individual resources: Deployment, Service, ConfigMap, and Secret. Then, template them using Helm.

📦 Step 4: Create a Custom Helm Chart

1

helm create myapp

This generates:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10

myapp/
├── charts/
├── templates/
│   ├── frontend-deployment.yaml
│   ├── backend-deployment.yaml
│   ├── postgres-deployment.yaml
│   ├── _helpers.tpl
│   ├── service.yaml
│   └── ingress.yaml
├── values.yaml

Example: frontend-deployment.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19

apiVersion: apps/v1
kind: Deployment
metadata:
  name: {{ .Release.Name }}-frontend
spec:
  replicas: 1
  selector:
    matchLabels:
      app: {{ .Release.Name }}-frontend
  template:
    metadata:
      labels:
        app: {{ .Release.Name }}-frontend
    spec:
      containers:
        - name: frontend
          image: "{{ .Values.frontend.image.repository }}:{{ .Values.frontend.image.tag }}"
          ports:
            - containerPort: 80

Example: values.yaml

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18

frontend:
  image:
    repository: myregistry/frontend
    tag: "latest"

backend:
  image:
    repository: myregistry/backend
    tag: "latest"

postgres:
  image:
    repository: postgres
    tag: "15-alpine"
  env:
    POSTGRES_DB: app
    POSTGRES_USER: user
    POSTGRES_PASSWORD: pass

🚢 Step 5: Deploy to Kubernetes

1

helm install myapp ./myapp --namespace my-namespace --create-namespace

Need to update?

1

helm upgrade myapp ./myapp

🧹 Cleanup

1
2

helm uninstall myapp --namespace my-namespace
kubectl delete namespace my-namespace

🔐 Managing CA Certificates in DevOps Environments

When deploying secure applications, especially in containerized or multi-service environments, your workloads need to trust Certificate Authorities (CAs). This ensures that HTTPS, TLS, and mTLS connections work correctly across Docker, Kubernetes, and JVM-based applications.

🧩 Why It Matters

If your backend calls external APIs, databases, or internal services over HTTPS, your containers must trust the issuing CA of those certificates — otherwise you’ll see errors like:

1

x509: certificate signed by unknown authority

This usually means your CA isn’t installed in the trust store.

🪜 Understanding the CA Chain

A Certificate Authority chain (also known as a “trust chain”) establishes trust between the server’s TLS certificate and a root authority your system already trusts.

It typically looks like this:

1

Root CA → Intermediate CA(s) → Leaf/Server Certificate

🧠 Components of the Chain

1. Root CA – The top-level authority (e.g., DigiCert, Let’s Encrypt, or your internal PKI root).

   • Preinstalled in the OS or Java keystore.

2. Intermediate CA – A delegated authority signed by the root; used for scalability and security.

   • Often multiple intermediates exist between root and server.

3. Server Certificate (Leaf) – The certificate installed on your app, load balancer, or ingress.

   • Signed by an intermediate CA.

When a TLS handshake occurs, the server presents its certificate chain to the client.

The client verifies:

• Each certificate was signed by the next one up,

• The top-most certificate (Root CA) exists in its trust store.

If any link in the chain is missing or invalid, you’ll see handshake errors like:

1
2

unable to verify the first certificate
certificate signed by unknown authority

🧩 Why Intermediate CAs Exist

Intermediate CAs are critical for security and scalability in any modern PKI:

Why it matters:

• 🧱 The Root CA stays offline (cold storage or HSM).

• ⚙️ Intermediates handle day-to-day certificate issuance.

• 🛡️ If an intermediate is compromised, it can be revoked independently of the root.

• 🧩 Enterprises can delegate intermediates per environment (e.g., staging, prod) or per region.

🔐 Example Real-World Chain

Using OpenSSL to inspect the trust path:

1

openssl s_client -connect norbix.dev:443 -showcerts

Typical output:

1
2
3
4
5
6

0 s:/CN=api.norbix.dev
  i:/CN=Norbix Intermediate CA
1 s:/CN=Norbix Intermediate CA
  i:/CN=Norbix Root CA
2 s:/CN=Norbix Root CA
  i:/CN=Norbix Root CA

Here:

• Certificate 0 – your server cert (leaf).

• Certificate 1 – your Intermediate CA (signed by the Root).

• Certificate 2 – your Root CA (self-signed).

🧩 Building a Full Chain File

In some deployments (especially Nginx or Ingress controllers), you must provide a full-chain certificate combining all components:

1

cat server.crt intermediate.crt rootCA.crt > fullchain.pem

Use this file in configurations such as:

1
2

ssl_certificate /etc/nginx/certs/fullchain.pem;
ssl_certificate_key /etc/nginx/certs/server.key;

The same principle applies to Ingress resources in Kubernetes (using tls.crt inside Secrets).

🔗 Visualizing a Multi-Level PKI

flowchart TD
   A["Root CA Offline"] --> B["Intermediate CA Prod"]
   A --> C["Intermediate CA Staging"]
   B --> D["Server Cert API"]
   C --> E["Server Cert Staging"]
   D --> F["Client"]
   E --> F
   F -->|Validates chain| A

• Root CA signs multiple Intermediates for different environments.

• Each Intermediate signs server certificates for its zone.

• Clients only need to trust the Root CA — the full chain provides cryptographic proof.

🔐 How Validation Actually Works

When a client (browser, API consumer, app, etc.) connects to your HTTPS endpoint:

1. Server presents the certificate chain during the TLS handshake:

   1 2 3

   Leaf (Server Cert) + Intermediate CA(s) + Optional Root (sometimes omitted)

2. Client builds the trust path:

   1	Leaf → Intermediate → Root

3. The client:

   • Verifies each signature:

   • “Was this cert signed by the next one in the chain?”

   • Checks expiration dates.

   • Ensures the Root CA public key exists in its local trust store (e.g., /etc/ssl/certs/ or $JAVA_HOME/lib/security/cacerts).

4. ✅ If the chain is valid and ends at a trusted Root CA → the certificate is accepted.

   ❌ If the Root CA is missing or untrusted → x509: certificate signed by unknown authority.

🏛 Why the Root CA Is Offline

• The Root CA’s private key is the “master key” of your PKI.

  If it’s ever compromised, every certificate under it becomes untrustworthy.

• To protect it:

  • The Root CA’s private key lives in an HSM, air-gapped server, or cold storage.

  • It’s only used once in a while to:

    • Sign or renew Intermediate CAs.

    • Issue CRLs (Certificate Revocation Lists) or OCSP signing certs.

So the Root CA only acts as a signer of Intermediate CAs, not as an active participant in client validation.

🔍 Client Trust Flow (Step by Step)

Let’s visualize this:

flowchart TD
  A["Root CA (Offline Key)"] -.-> B["Intermediate CA (Online Issuer)"]
  B --> C["Server Certificate"]
  C --> D["Client"]

  D -->|Validates Signature Chain Locally| A

What Happens:

• A (Root CA) has its public certificate installed in the OS/browser.

• B (Intermediate CA) signs leaf certs and is online.

• C (Server cert) is presented by the server.

• D (Client) validates the signatures locally, using cached Root CA info.

🐧 CA Certificates in Linux

Trusted CAs are managed system-wide and stored in platform-specific locations:

To add a custom CA:

1
2

sudo cp my-root-ca.crt /usr/local/share/ca-certificates/
sudo update-ca-certificates

Inside a Dockerfile (Debian/Ubuntu base):

1
2

COPY my-root-ca.crt /usr/local/share/ca-certificates/
RUN update-ca-certificates

☕ CA Certificates in the JVM (Java & Spring Boot Apps)

JVM apps don’t use the OS trust store by default. They rely on the Java keystore:

1

$JAVA_HOME/lib/security/cacerts

• Default password: changeit

• Managed using the keytool utility.

Add your CA to the keystore:

1
2
3
4
5

sudo keytool -importcert \
  -trustcacerts \
  -file my-root-ca.crt \
  -alias myrootca \
  -keystore $JAVA_HOME/lib/security/cacerts

Verify:

1

keytool -list -keystore $JAVA_HOME/lib/security/cacerts | grep myrootca

For containerized Java apps, mount or bake the updated keystore into your image.

CAs in Kubernetes

You can mount custom CA bundles into pods via ConfigMaps or Secrets.

Example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

apiVersion: v1
kind: ConfigMap
metadata:
  name: custom-ca
data:
  my-root-ca.crt: |
    -----BEGIN CERTIFICATE-----
    MIID...
    -----END CERTIFICATE-----
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
spec:
  template:
    spec:
      volumes:
        - name: ca-cert
          configMap:
            name: custom-ca
      containers:
        - name: backend
          image: myregistry/backend
          volumeMounts:
            - mountPath: /usr/local/share/ca-certificates/my-root-ca.crt
              subPath: my-root-ca.crt
          env:
            - name: SSL_CERT_DIR
              value: /usr/local/share/ca-certificates

This ensures all HTTPS clients inside the container trust your internal CA.

✅ Quick Tips

• Always verify your containers include updated ca-certificates packages.

• Use CI/CD build steps to refresh CAs for long-lived images.

• For internal APIs, prefer short-lived certs from an internal CA (Vault, Smallstep, or cert-manager).

🧭 Visualizing the Trust Chain Across Platforms

flowchart TB
    subgraph PKI["🏛️ Public Key Infrastructure"]
        A["Root CA (Offline)"]
        B["Intermediate CA"]
        C["Server Certificate (Leaf)"]
    end

    subgraph Linux["🐧 Linux System"]
        D["/etc/ssl/certs/"]
        E["update-ca-certificates"]
    end

    subgraph Docker["🐋 Docker Container"]
        F["ca-certificates package"]
        G["/usr/local/share/ca-certificates/*.crt"]
    end

    subgraph JVM["☕ JVM Environment"]
        H["$JAVA_HOME/lib/security/cacerts"]
        I["keytool import"]
    end

    subgraph K8s["☸️ Kubernetes"]
        J["ConfigMap / Secret with fullchain.pem"]
        K["Mounted to Pod at /usr/local/share/ca-certificates/"]
    end

    A --> B --> C
    C --> D --> F --> G
    G --> H --> I
    G --> J --> K

Flow:

1. Root and Intermediate CAs are distributed from your PKI.

2. They’re installed into Linux, Docker images, or JVM keystores.

3. Kubernetes workloads mount or inherit these trust stores to enable secure HTTPS connections.

🌐 End-to-End Trust Flow Inside a Kubernetes Cluster

To visualize how certificates propagate and maintain trust between components within a live Kubernetes environment:

flowchart TB
   subgraph Cluster["☸️ Kubernetes Cluster"]
      A["Ingress Controller (Nginx / Traefik)"]
      B["Backend Service (Go API)"]
      C["Pod with Mounted CA Bundle"]
      D["PostgreSQL Service / External API"]
   end

   subgraph PKI["🏛️ Internal / External PKI"]
      E["Root CA"]
      F["Intermediate CA"]
      G["Issued Server Certs"]
   end

   E --> F --> G
   G --> A
   G --> B
   G --> D

   A -->|TLS Handshake| B
   B -->|Mutual TLS / HTTPS| D
   C -->|Uses mounted trust store| F

   A -.->|Validates chain against Root CA| E
   B -.->|Trusts mounted CA certs| E

Flow Explanation:

1. 🔐 Root and Intermediate CAs issue server and client certificates (via cert-manager, Vault, or your internal PKI).

2. 🧱 The Ingress Controller presents a full certificate chain (tls.crt with intermediates).

3. ⚙️ The Backend Service validates this chain using system or mounted CAs.

4. ☁️ The Pod includes a ConfigMap or Secret-mounted trust store for external HTTPS calls.

5. 🧩 All communication — ingress to service to external API — relies on the same root of trust.

This ensures end-to-end security across:

• Internal service-to-service communication

• External API calls

• Database or message broker TLS connections

🔐 What Is Mutual TLS (mTLS)

So far, we’ve talked about one-way TLS, where the client verifies the server’s identity.
Mutual TLS (mTLS) extends this idea — it makes both sides authenticate each other using X.509 certificates.

In a standard TLS handshake:

• The server presents its certificate chain (so the client knows it’s talking to the right endpoint).
• The client simply trusts that certificate based on its CA bundle.

In mTLS, an additional step occurs:

• The client also presents its own certificate to the server.
• The server verifies the client certificate against its trusted CA store.

That means:

• The client authenticates the server ✅
• The server authenticates the client ✅

This creates mutual trust — useful in microservices, APIs, and internal systems where both ends need to verify identity.

🧩 mTLS in Practice

Once both sides complete validation, the TLS session is established and encrypted.

🧱 mTLS in Kubernetes

mTLS is commonly used between microservices, sidecars, or service meshes like Istio or Linkerd.

Example setup with cert-manager or Vault:

• Each service gets its own certificate and key (often short-lived).
• Services trust a shared Root or Intermediate CA.
• The service mesh injects sidecars that handle mTLS transparently.

☸️ Example: Go API with mTLS Validation

If your Go-based backend connects securely to another internal service:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12

cert, _ := tls.LoadX509KeyPair("client.crt", "client.key")
caCert, _ := os.ReadFile("rootCA.crt")

caPool := x509.NewCertPool()
caPool.AppendCertsFromPEM(caCert)

tlsConfig := &tls.Config{
    Certificates: []tls.Certificate{cert}, // client certificate
    RootCAs:      caPool,                  // trust server CA
    ClientCAs:    caPool,                  // verify client CA (on server)
    ClientAuth:   tls.RequireAndVerifyClientCert,
}

This configuration ensures:

• The client proves its identity with its certificate.

• The server verifies the client’s cert against a trusted CA.

• Both endpoints encrypt traffic and authenticate each other.

🔐 Benefits of mTLS

• 🧭 Strong identity assurance between services.

• 🧱 Zero-trust networking — authentication is built into every connection.

• 🔒 Defense in depth — even if network boundaries are breached, only valid certs can communicate.

• ⚙️ Automatable with cert-manager, Vault, or SPIRE for rotation and issuance.

• 🧩 Visualizing Mutual TLS

flowchart TD
    subgraph ServiceA["Service A (Client)"]
        A1["Client Certificate + Key"]
    end

    subgraph ServiceB["Service B (Server)"]
        B1["Server Certificate + Key"]
    end

    subgraph PKI["🏛️ Shared PKI"]
        R["Root / Intermediate CA"]
    end

    A1 -->|presents cert| B1
    B1 -->|presents cert| A1
    A1 -->|verifies via CA| R
    B1 -->|verifies via CA| R

Both sides use certificates issued from the same trust root, and the handshake only succeeds when each validates the other’s chain.

🧠 In short:

• TLS guarantees confidentiality and server authenticity,

• mTLS guarantees confidentiality, integrity, and mutual identity verification — making it essential for secure microservice communication inside Kubernetes clusters or service meshes.

DORA Metrics for DevOps Success

DORA (DevOps Research and Assessment) metrics help measure software delivery performance. Focus on:

flowchart LR
    subgraph Speed["⚡ Speed"]
        DF["Deployment Frequency<br/>(How often do you deploy?)"]
        LT["Lead Time for Changes<br/>(Commit → Production time)"]
    end

    subgraph Stability["🛡️ Stability"]
        CFR["Change Failure Rate<br/>(% of deployments causing failures)"]
        MTTR["Mean Time to Restore<br/>(Time to recover from incidents)"]
    end

    DF -->|frequent releases| Speed
    LT -->|fast feedback loop| Speed
    CFR -->|fewer failures| Stability
    MTTR -->|quick recovery| Stability

1. Deployment Frequency DF

   ➡️ How often code is deployed to production.

   • High-performing teams: deploy on-demand, multiple times a day.

   • Low-performing teams: deploy monthly or less.

   • Goal: Ship value quickly and iteratively.

2. Lead Time for Changes LT

   ➡️ Time from code commit → successfully running in production.

   • Measures delivery speed.

   • Elite performers: <1 day.

   • Low performers: >1 month.

   • Goal: Shorter lead times = faster feedback loops.

3. Change Failure Rate CFR

   ➡️ Percentage of deployments that cause failures (bugs, outages, rollbacks).

   • Elite teams: 0–15% failure rate.

   • Goal: Keep failure rates low, even with high deployment frequency.

4. Mean Time to Restore MTTR

   ➡️ How long it takes to recover from a failure in production.

   • Elite teams: <1 hour.

   • Goal: Detect issues quickly and restore service fast.

📊 Why They Matter

• They provide objective data on DevOps maturity.

• Balance speed vs reliability (no point deploying daily if systems keep breaking).

• Help teams focus on outcomes, not vanity metrics (like “number of commits”).

⚙️ How to Track DORA Metrics

• Version Control (GitHub/GitLab): commits & PR timestamps.

• CI/CD pipelines (Jenkins, GitHub Actions, ArgoCD): deployment events.

• Monitoring/Observability (Prometheus, Grafana, Datadog): incidents, MTTR.

• Incident management (PagerDuty, OpsGenie): failure tracking.

🏆 Benchmarks (from Google’s 2022 DevOps Report)

👉 In short: DORA metrics are the KPIs of DevOps — they tell you how fast you deliver and how resilient you are.

🎯 Final Thoughts

By combining Docker, Kubernetes, and Helm, you get:

• A repeatable deployment pipeline
• Configurable environments per stage (via Helm)
• Easy rollbacks and upgrades

Helm lets you treat infrastructure like code—enabling DevOps best practices like versioning, templating, and CI/CD automation.

🚀 Follow me on norbix.dev for more insights on Go, Python, AI, system design, and engineering wisdom.
